24' HVLS Ceiling Fan - Hunter Titan Series

We supply Hunter and MacroAir HVLS ceiling fans for industrial facilities, warehouses, and large commercial spaces. Both lines use direct drive permanent magnet motors, gearless and oil-free, with no belts or gearboxes to maintain. The right fan depends on your ceiling height, space size, structural capacity, and noise requirements. We size and spec both.

The Hunter Titan uses a 5-blade aircraft-grade aluminum design with IP54 dust and moisture protection. At 204 lbs for the 24-foot model it is one of the lightest options in its class, which reduces structural reinforcement requirements and simplifies installation. Integrated fire panel relay and Quick Connect mounting are standard.

The MacroAir AVDX starts at 8 feet, making it the better fit for facilities with lower ceilings or tighter spaces. It runs down to 33 dBA, which is among the quietest HVLS fans available, and uses a 6-blade design. Both fans are made in the USA and compatible with touchscreen and BMS/PoE controls.

Key Capabilities — Both Lines

• Maintenance-free gearless direct drive motors — no oil, no belts, no gearboxes
• Made in the USA
• Compatible with touchscreen and BMS/PoE building controls
• Integrated fire panel relay for automatic emergency shutdown
• Multiple sizes available — Hunter from 14′, MacroAir from 8′
• Contact us to spec the right fan for your facility.

Specification	Hunter Titan 24′	MacroAir AVDX 24′
Motor Technology	Direct Drive Permanent Magnet — gearless, oil-free	Direct Drive Permanent Magnet — gearless, oil-free
Max Airflow	325,000 CFM ★	246,625 CFM
Coverage Area	Up to 22,500 sq ft ★	Up to 22,000 sq ft
Max Speed	70 RPM	60 RPM
Hanging Weight	204 lbs ★	213 lbs
Number of Blades	5	6
Sound Level	Less than 55 dBA	Down to 33 dBA ★
Input Voltage	200–480V; single and 3-phase	208–240V or 480V; single and 3-phase
IP / Environment Rating	IP54 — dust and moisture protected	Rated indoor/outdoor
Blade Construction	Aircraft-grade aluminum; structural steel holder	Clear-coat anodized aluminum airfoils
Controls	Touchscreen or PoE BMS integration	Digital wall control + VFD; BMS via AirLynk upgrade
Fire Relay	Standard	Standard via VFD
Smallest Size Available	14′ minimum	8′ minimum ★
Made in USA	Yes	Yes

★ = advantage in this category. Both fans available in 14–24′ overlap sizes. Contact us to spec the right fan for your facility.

Who This Is For

HVLS fans are the right fit for any large facility where air movement, temperature stratification, or worker comfort is a problem. Common applications we see in Indiana facilities include:

• Warehouses and distribution centers with hot upper air and cold floor zones
• Manufacturing and fabrication shops needing whole-facility air circulation
• Agricultural buildings, equestrian facilities, and large barns
• Facilities with lower ceilings (8 feet and up) where standard HVLS fans won’t fit
• Operations in food processing, automotive, or logistics needing quiet, continuous airflow
• Any facility looking to reduce heating and cooling costs through better air destratification

Problems This Solves

• Eliminates temperature stratification that drives up heating costs in winter and cooling costs in summer
• Reduces heat stress for workers on open production floors during summer months
• Replaces multiple smaller high-speed fans with one low-noise, low-maintenance unit
• Cuts energy costs compared to running additional HVAC to compensate for poor air circulation
• Eliminates gearbox and belt maintenance required by older fan designs
• Automatically shuts down via fire panel relay integration during emergency events
