MacroAir HVLS Fans

Name: Collectors & Filters
Address: PO Box 04, Whitetown, Indiana, 46075, US
Telephone: 317-910-1497
Price range: $

Collectors & Filters sells and support MacroAir to bring their HVLS fan systems to facilities throughout Indiana and the Midwest. We help you select the right fan for your space, provide layout assistance, and connect you with the support you need.

MacroAir invented HVLS technology in 1998 and has refined it ever since. Unlike standard high-speed fans that create chaotic turbulence, their blade design and direct-drive motors deliver efficiency with only two moving parts. You get whisper-quiet operation at 53 dB and annual energy savings which vary by facility size and usage.

📞 317-910-1497

The MacroAir Advantage

Two moving parts. That’s it. MacroAir’s direct-drive architecture eliminates the gearbox entirely: no oil changes, no bearing replacements, no scheduled downtime. The result is a 50,000-hour warranty (that’s 28 years of continuous operation). Less moving parts means reduces friction, maintenance, and noise.

Key Specifications & Benefits

Coverage Area up to 20,000 sq ft: A single fan creates a massive vertical air column that pushes stratified ceiling air downward and outward. One fan replaces dozens of high-speed units.
33-61 dB Sound Level (depending on size and model): Library-quiet operation at maximum speed. Traditional gear-driven fans, small high-velocity, run at higher dB sounds (generally between 50-60). Your team can hold conversations.
AirBrain Processor with Adaptive Voltage Control: MacroAir’s patented AirBrain compensates for fluctuations across 100-480V input without a separate VFD. That’s $2,000 to $5,000 in control components you don’t need to buy.
Anodized Aluminum NASA Airfoil Blades: Extruded and clearcoat-finished for corrosion resistance. Built for warehouses, agricultural facilities, and outdoor washdown environments.

Why Choose MacroAir?

Reliability matters. Whether you are running a pharmaceutical warehouse or a dairy barn, you need equipment that meets your needs and thermal comfort standards.

How Can We Help

We don’t just ship parts; we provide solutions. Collectors & Filters handles the technical calculations and system design to ensure your project lands on time and under budget.

Contact us today to spec the right system for your facility.

MacroAir HVLS fans are designed, engineered, and manufactured in Colton, California. How can we help? Collectors & Filters, Whitestown, Indiana — 317-910-1497.

Category	MacroAir Advantage	What Most HVLS Fans Do	Why It Matters
Engineering & Drive System
Drive System	✓ Direct-drive PMAC motor, only 2 moving parts	Gearbox-driven requires oil changes and bearing replacements	No gearbox means zero scheduled maintenance and the number one failure point eliminated
Controls	✓ Built-in AirBrain processor with Adaptive Voltage Control, auto 100–480V	Separate VFD required, additional cost and installation	No extra VFD to buy, install, or maintain — handles voltage swings automatically
Blade Design	✓ 6ixBlade patented NASA-optimized airfoil, extruded anodized aluminum with clearcoat	Standard aluminum or composite blades without optimized airfoil geometry	Superior air column depth and full corrosion resistance in harsh environments
Performance & Coverage
Coverage Area	✓ Up to 22,000 sq ft per fan at 24 ft diameter	10,000 to 14,000 sq ft at the same diameter on most competing fans	Fewer fans needed, lower installed cost, and simpler electrical layout
Size Range	✓ 8 ft to 24 ft diameters across the AVDX series	Most lines start at 10 to 14 ft minimum, leaving small spaces without a quality option	One product family covers small shops through massive warehouses and distribution centers
Sound Level	✓ Library-quiet 50 to 53 dBA at full speed	Gear-driven models run 70 dBA or higher	Employees can communicate normally and OSHA noise exposure limits are not a concern
Integration & Compliance
Building Automation	✓ Native BACnet and LonWorks compatible	Proprietary controls only, requiring additional gateways for BMS integration	Connects directly into existing building management systems with no extra hardware
Certifications	✓ AMCA certified airflow, NFPA 70 and UL compliant	Not all manufacturers publish third-party certified performance data	Verified numbers you can use for engineering specs, insurance documentation, and permit drawings

Proudly designed, engineered & manufactured in Colton, California, USA

Frequently Asked Questions — MacroAir HVLS Fans

What is an HVLS fan and how does it work?

MacroAir HVLS fans use large-diameter blades spinning at low RPM to move massive volumes of air gently and efficiently. A single fan generates a wide vertical air column that pushes stratified warm air down from the ceiling and circulates it outward across the floor. This creates a consistent temperature throughout the facility without the turbulence or noise of traditional high-speed fans. See how HVLS fans fit into a complete industrial ventilation system.

Who invented HVLS fan technology?

MacroAir invented HVLS fan technology in 1998. They have refined the design ever since and continue to manufacture their fans in Colton, California. As the originator of the category, MacroAir holds multiple patents covering blade geometry, motor architecture, and control systems. We also supply Hunter Industrial HVLS fans if you want to compare options.

How much square footage can one MacroAir fan cover?

A single MacroAir fan can cover up to 22,000 square feet depending on the model and ceiling height. Their largest 24-foot diameter fans in the AVDX series are engineered to replace dozens of standard high-speed pedestal or ceiling fans. Proper layout and fan selection are critical to achieving full coverage. Contact us with your building dimensions and we will size it for you.

What sizes do MacroAir fans come in?

MacroAir fans are available in diameters from 8 feet to 24 feet across the AVDX series. This range covers small machine shops, large distribution warehouses, agricultural buildings, and everything in between. Collectors & Filters can help you determine the right size for your ceiling height, layout, and occupancy type. We serve Indiana manufacturers and surrounding states.

How loud are MacroAir HVLS fans?

MacroAir fans operate between 50 and 53 dBA at full speed, comparable to a quiet library. Employees can hold normal conversations directly beneath the fan. Traditional gear-driven fans and small high-velocity units typically run louder, making MacroAir a strong choice for facilities where communication, focus, or noise compliance matters. This pairs well with dust collection systems that also need to keep shop noise manageable.

Do MacroAir fans require a separate variable frequency drive?

No. MacroAir fans include the patented AirBrain processor with Adaptive Voltage Control built into the unit. This automatically compensates for voltage fluctuations across a 100 to 480 volt input range, eliminating the need for a separate VFD. Depending on your facility, that can represent $2,000 to $5,000 in control components you will not need to purchase, install, or maintain.

How many moving parts does a MacroAir fan have?

Two. MacroAir uses a direct-drive PMAC motor that eliminates the gearbox found in traditional HVLS fans. No gearbox means no oil changes, no bearing replacements, and no scheduled downtime for drivetrain maintenance. This is the primary reason MacroAir backs their fans with a 50,000-hour warranty, roughly 28 years of continuous operation. For comparison, our maintenance guide shows what routine upkeep looks like on dust collection equipment with more moving parts.

What is the MacroAir warranty?

MacroAir provides a 50,000-hour warranty on their direct-drive motor systems. At continuous operation, that equals approximately 28 years. This warranty is made possible by the two-moving-part design, which removes the gearbox as the primary failure point in conventional fan systems. See the full MacroAir product page for details.

Can MacroAir fans integrate with a building automation system?

Yes. MacroAir fans support native BACnet and LonWorks communication protocols. This allows direct integration without additional gateways or proprietary adapters. Facilities with existing BMS infrastructure can add MacroAir fans without modifying their control architecture. This also makes it straightforward to coordinate fan operation with industrial ventilation systems running in the same facility.

How do I get help selecting the right MacroAir fan for my facility?

Collectors & Filters handles fan selection, layout planning, and system design for Indiana manufacturers and facilities in Northern Kentucky and Southern Michigan. We work through the technical calculations to make sure you get the right fan count, diameter, and placement for your building. Call 317-910-1497 or use the contact form to get started.
