Most Dust Collection Systems Are Sized to Sell Filters.
Ours Are Not.
If your dust collector chews through filters, loses suction at the hood, or never
worked right from day one, it was probably sized wrong. Not because the equipment
is bad but because someone skipped the engineering and picked a collector
off a catalog. Most people asking how to size a dust collector get sold
filter area instead of engineering.
The trap is simple. Filter area is easy to upsell. Airflow takes real work to
calculate. So a lot of vendors quote you a collector based on total filter square
footage, promise “plenty of capacity,” and move on. Six months later you’re buying
replacement filters every
quarter because the system was never matched to your process in the first place.
We do it differently. We size to airflow and process, you know,
the stuff that actually determines whether your system works.
What We Actually Look At
Before we quote anything, we work through three questions about your shop:
- What’s making the dust? Wood chips,
weld fumes,
grain, metal grinding, and chemical powder all behave differently. Each one needs
a different kind of collector and a different airflow strategy. - How much air does each pickup need? A table saw, a
welding booth,
and a bag-dump station all pull different volumes. Add them up correctly or
you’ll starve half your pickups. - What does the building look like? Where the collector sits,
how the duct runs, and how tall the ceiling is all change the design.
Get those three right and the rest of the sizing math takes care of itself.
The Five Numbers That Actually Matter
Here’s what real sizing looks like:
- CFM (cubic feet per minute): How much air the system moves.
Every pickup point has a required minimum. - Capture velocity: How fast the air moves at the dust source.
Too slow and dust escapes before it’s captured. - Transport velocity: How fast the air moves inside the duct.
Too slow and material falls out and clogs the duct. - Static pressure: How hard the fan has to work to pull air
through the whole system. Get this wrong and the collector is underpowered on
day one. - Air-to-cloth ratio: The relationship between airflow and
filter area. This is where the filter-count trap happens. Set it wrong for your
dust and you blind filters fast, no matter how many you installed.
Filter surface area is the last variable we look at, not the first.
Equipment We Size and Supply
Once the numbers are right, we match the application to the correct equipment.
For cartridge-style collectors, we carry
A.C.T. Dust Collectors
and
AGET Manufacturing,
both well-suited to general industrial and metalworking applications. For larger
baghouse systems and high-load industrial processes, we represent
CECO Environmental,
including the Flex-Kleen baghouse line. Other manufacturers are available depending
on your application. Contact us
with your process details and we will size the system and quote the right equipment
for your shop.
Cartridge, Baghouse, or Cyclone?
Once we know your process and airflow, the equipment choice gets simple.
Most shops need one of three:
- Cartridge collectors for fine dust; laser cutting, welding fume, dry fine particulate. Compact, efficient, easy filter changes. Flex-Kleen and A.C.T. are our primary cartridge lines.
- Baghouses for high-volume and heavy loads; foundry, grain, cement, continuous production. Handle big dust loads that would blind a cartridge collector in weeks. We represent the Flex-Kleen baghouse line through CECO Environmental for these applications.
- Cyclones for heavy chips and shavings; woodworking, planing, sawmill. Often used as a first stage before a cartridge or baghouse to drop out heavy material and extend filter life.
We’ll recommend the right one for your process and tell you straight if you don’t
need the expensive option. Contact us with your application and we’ll size it and quote it at no charge.
Confused about how to size a dust collector?
Skip the guesswork. Talk to the owner.
A system with 5 pickup points requiring 500 CFM each needs at least 2,500 CFM of total airflow. After accounting for ductwork losses and filter resistance, and the fan a collector must be sized to maintain that airflow under full operating (dirty filter) conditions.
Systems must be sized based on dirty-air performance, since pressure drop increases as filters load during normal operation.
Also a system should always account for duct losses, static pressure loss throughout, and filter load over time.
Because real sizing is NOT just CFM numbers.
Typical Airflow Requirements by Machine or Process
Every pickup point has its own CFM requirement. Here are common starting numbers — actual values depend on hood design, duct run, and operating conditions:
| Machine / Process | Typical CFM Required | Transport Velocity | Collector Type |
|---|---|---|---|
| Table saw | 350 – 550 CFM | 4,500 FPM | Cyclone only or W/Baghouse |
| CNC router | 800 – 1,500 CFM | 4,000 FPM | Cyclone W/Baghouse or Cartridge |
| Wide-belt sander | 1,200 – 2,000 CFM | 3,500 FPM | Cartridge or Baghouse |
| Upcut aluminum saw | 600 – 1,500 CFM | 4,500 FPM | Cyclone W/ Mist Collection |
| Welding booth (per station) | 800 – 1,200 CFM | 2,500 FPM (fume) | Cartridge |
| Grinding booth | 250 CFM per sq ft opening | 4,500 FPM | Cartridge or Baghouse |
| Plasma / laser cutting table | 2,500 – 5,000 CFM | 4,000 FPM | Cartridge (HEPA for laser) |
| Bag dump / powder transfer | 400 – 1,000 CFM | 3,500 FPM | Cartridge or HEPA — combustible dust rules apply |
| Grain handling (per transfer) | 500 – 1,500 CFM | 4,000 FPM | Baghouse w/ explosion vent |
| Foundry shakeout | 4,000 – 15,000+ CFM | 4,500 FPM | Baghouse (high-temp) |
Actual CFM requirements vary by hood design, duct geometry, and operating conditions. These numbers are starting points. We run the calculations for your specific setup.
Why Oversized Filter Area Isn't a Feature
You’ll see a lot of quotes brag about filter square footage. That’s not always a good thing. If the air-to-cloth ratio is wrong for your dust type, more filter area doesn’t help it just means more filters to replace when they blind up.
A properly sized system uses the right filter area for your dust. Not the most. Done correctly, filter life stretches from months to years.
How To Size A Dust Collector:
How We Work
-
We visit or talk through your process.
What you make, what machines run, how often they run, and what you're seeing now. -
We run the calculations.
CFM per pickup, total airflow, duct velocity, static pressure, air-to-cloth ratio. Real numbers, not catalog picks. -
We quote the right system.
Equipment, ducting, installation, and startup; sized to your process and nothing else.
What Also Determines Dust Collector Size
-
Dust type matters more than volume.
Wood chips, welding fumes, and chemical powder need completely different collectors. A system sized by CFM alone will fail if it ignores what's in the air. -
Ductwork can make or break suction.
Undersized duct, too many sharp elbows, or the wrong transport velocity will starve pickups no matter how big the collector is. -
Makeup air is often forgotten.
If you're pulling 5,000 CFM out of a building, you need 5,000 CFM coming back in. Ignore this and your system fights the building itself. -
Explosion risk adds a layer of design.
Combustible dust: wood, grain, aluminum, sugar, organic powders all requires spark detection, abort gates, or vent panels. We flag it upfront, not after an inspector does.
Not Sure Which System Fits Your Shop?
We’ll review your process, facility layout, and current problems, then recommend the right equipment, whether that’s a single cartridge collector or a full multi-drop baghouse system.
Zero sales pressure.
Straight answers from the company that has been sizing systems since 1955.
