YMX 5000 IR Spark Detection and Suppression Systems

The YMX 5000 is purpose-built to withstand the abrasive conditions and temperature extremes found in industrial material handling. Unlike standard commercial detectors, the sensor units feature 316 stainless steel housings and flush-mounted lenses that resist wear from high-velocity wood chips, metal grindings, and polymer dust. This rugged construction allows the system to maintain a wide operating temperature range of -40°F to +221°F, making it the only viable solution for both freezing outdoor cyclones and high-heat drying processes. Reliability in these hazardous locations is guaranteed through our industry-exclusive “through-the-lens” self-testing technology. While other systems require manual checking, the YMX 5000 continuously verifies optical integrity and circuit continuity. This feature is critical for compliance in Class II, Division 1 & 2 and ATEX zones, ensuring that lens contamination from heavy dust loads is detected immediately before it compromises safety.

Key Capabilities

• Reaction Time: Detects and extinguishes sparks in < 300ms
• Reliability: Automatic “through-the-lens” optical self-testing
• Durability: 316 Stainless Steel housing rated to 221°F
• Compliance: FM Global Approved and NFPA compliant
